1.Material: AISI302, 304,316,316L,310S,410,430,904L,2205,2507,etc
2.Wire Diameter: 0.015-2.8mm
3.Mesh count:
Plain weave can be woven up to 400 mesh.
Twill weave can be woven from 400 to 635mesh.
Dutch weave can be woven up to 3500mesh
4.Weave pattern: Plain Weave ,Twill Weave,Dutch Weave,etc.
5.Features:
- Corrosion resistance.
- Anti-acid and alkali
- Anti-high temperture.
- Good filter performance.
- Long using life
6.Application:
- In acid, alkali environment conditions sieving and filtering.
- Petroleum industry as mud mesh,.
- Chemical fiber industry as screen mesh.
- Plating industry as acid cleaning mesh.
Specification
Stainless Steel Wire Mesh |
|||
Mesh/inch | Wire Diameter | Aperture | Aperture |
(mm) | (mm) | (mm) | |
2mesh | 1.8 | 10.9 | 0.273 |
3mesh | 1.6 | 6.866 | 0.223 |
4mesh | 1.2 | 5.15 | 0.198 |
5mesh | 0.91 | 4.17 | 0.172 |
6mesh | 0.8 | 3.433 | 0.154 |
8mesh | 0.6 | 2.575 | 0.132 |
10mesh | 0.55 | 1.99 | 0.111 |
12mesh | 0.5 | 1.616 | 0.104 |
14mesh | 0.45 | 1.362 | 0.094 |
16mesh | 0.4 | 1.188 | 0.088 |
18mesh | 0.35 | 1.06 | 0.074 |
20mesh | 0.3 | 0.97 | 0.061 |
26mesh | 0.28 | 0.696 | 0.049 |
30mesh | 0.25 | 0.596 | 0.048 |
40mesh | 0.21 | 0.425 | 0.042 |
50mesh | 0.19 | 0.318 | 0.0385 |
Width of Stainless Steel Wire Mesh: 0.6m-8m |
Packaging Details
a.High mesh count:Inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
b.Low mesh count:Packed in rolls,Then with waterproof and woven bags,Finally in wooden case
c.Sheet shape:Inside with plastic film and outside with a small wooden case
Why choos us
Professional & experienced factory(over 20 years)
Professional design team& excellent sales team for your service;
Quick delivery& superior quality
Alibaba golden supplier& SGS report
Our Services
OEM | Yes |
Special Sizes or Shape | Yes |
Customized packing | Yes |
Sample | Can be offered or Made |
Delivery time | Usually within 7-15 working days |
Payment terms | T/T, Western Union, PayPal., Escrow, L/C |
Optional Way of Transportation | Sea Transportation, Air Transportation
International Express: DHL,TNT,DEDEX,UPS,EMS |
